Bambu Lab PLA Carbon Fiber Filament 1.75mm 1kg Spool - High Strength 3D Printing Material for Cosplay, RC Cars & Engineering Prototypes
Free shipping on all orders over $50
7-15 days international
9 people viewing this product right now!
30-day free returns
Secure checkout
96552373
Description
Carbon Fiber Reinforced PLA
Bambu PLA-CF
Bambu PLA-CF is carbon fiber reinforced PLA with improved stiffness and strength. PLA-CF is easy to print and beginner-friendly like regular PLA. It is AMS compatible with low clogging risk at high-speed printing. The prints are in matte finish with almost invisible layer lines, which make it suitable for printing general engineering parts or models requiring a better appearance, like bike frames, brackets and toys.
Carbon fiber texture & Minimized layer lines
The addition of carbon fiber gives prints a unique matte finish and effectively hides layer lines, providing a smooth, premium look.
Display of Prints
Bambu PLA-CF could be paired with any PLA series filament to make your prints more colorful and achieve various texture requirements.
Improved mechanical properties
Bambu PLA-CF exceeds the mechanical properties of PLA Matte in XY Bending Strength, Z Bending Strength, XY Bending Modulus, Z Bending Modulus, XY Impact Strength, and Z Impact Strength by between 20% and 115%, making it more suitable for printing models with higher strength requirements.
Note:
• Dry out before use
• AMS compatible
Mechanical Properties Comparison
| PLA Matte | PLA-CF | Improved % | |
| Tensile Strength - XY/MPa | 32 | 38 | 19% |
| Tensile Strength - Z/MPa | 25 | 26 | 4% |
| Bending Strength - XY/MPa | 53 | 96 | 81% |
| Bending Strength - Z/MPa | 32 | 49 | 53% |
| Bending Modulus - XY/MPa | 2360 | 3700 | 57% |
| Bending Modulus - Z/MPa | 2040 | 2260 | 10% |
| Impact Strength - XY/(kJ/m²) | 19.2 | 23.2 | 20% |
| Impact Strength - Z/(kJ/m²) | 6.6 | 7.8 | 18% |
*Drying PLA is recommended for humid environments at 55 °C for 8 hours before printing.
Stabilized printing dimension
Bambu PLA-CF features low shrinkage and warping resistance to achieve a perfect matching accuracy between prints parts.
Minimal effort in support removal
Bambu PLA-CF is designed to support itself. It can be removed more easily compared to regular PLA, and still maintains a smooth support surface.
Recommended Printing Settings
| Drying Settings (Blast Drying Oven) | 55 °C, 8 h |
| Printing and Keeping Container's Humidity | < 20% RH (Sealed, with Desiccant) |
| Nozzle Temperature | 210 - 240 °C |
| Bed Temperature (with PVP Glue) | 35 - 45 °C |
| Printing Speed | < 200 mm/s |
Physical Properties
| Density | 1.22 g/cm³ |
| Vicar Softening Temperature | 69 °C |
| Heat Deflection Temperature | 55 °C |
| Melting Temperature | 165 °C |
| Melt Index | 3.7 ± 0.6 g/10 min |
Mechanical Properties
| Tensile Strength | 38 ± 4 MPa |
| Breaking Elongation Rate | 12.7 ± 3.4 % |
| Bending Modulus | 3700 ± 220 MPa |
| Bending Strength | 96 ± 3 MPa |
| Impact Strength | 23.2 ± 3.7 kJ/m² |
Printing Tips
• Drying PLA-CF is optional, but recommended for humid environments at 55℃ for 8 hours before printing.
What's in the Box
Filament with Spool*1 & Desiccant*1
Filament Label*1
Package*1
