AutoScan DS EX Dental 3D Scanner for Crowns, Bridges & Implants - High Precision Digital Dental Scanner for Dentists & Labs
Free shipping on all orders over $50
7-15 days international
21 people viewing this product right now!
30-day free returns
Secure checkout
41025297
Description
AutoScan-DS-EX is an unexpectedly cost-effective option for the dental market. This brand new 3D dental scanner will amaze the dental world with its unmatched small footprint and unprecedented light-weight. This will make it the ideal scanning solution for any dental service bureau and labs with restricted space.
AutoScan-DS-EX Cost-effective Dental 3D Scanner
AutoScan-DS-EX is specifically developed for the dental market. It adopts the latest structured light 3D scanning technology to provide accurate and efficient solutions for those who focus on productivity and cost-effectiveness.
The AutoScan-DS-EX 3D scanner provides an optimal data post-processing option through LAN net-work, and a revolutionary structure that allows easy upgrades for the foreseeable future. It is your ideal digital lab companion.
AutoScan-DS-EX 3D scanner can be applied to different levels of dental laboratories, dental vocational colleges, dental clinics, etc. Its intuitive design and automatic work-flow brings incredible benefits to dental labs and vocational education centers of dental technology.
Features
Fully Open Structure
Multiple Functions Available
· Articulator scanning : support the 3D scanning of most articulators available in the market, such as Artex, KAVO, etc.
· Triple-tray scanning : more convenient triple-tray impression scanning with optimized jig.
· Texture scanning : marks on dental models can be captured clearly, providing reference for further design work.
· Continuous Scanning ： The AutoScan-DS-EX 3D scanner provides an optimal data post-processing option through LAN net-work.
Clinic Mode Added
With the clinic mode, desktop 3D scanner can be applied to dental clinics directly to support chair-side restoration solutions.
Open Data Format
Export STL data, high compatibility with current open CAD/CAM software and hardware in the market.
Technical Specifications
| Model | AutoScan-DS-EX |
| Camera Resolution | 1.3 mega pixel |
| Accuracy | ＜15 µm |
| Scanning Range | 100 mm*100 mm*75 mm |
| Scanning Time | bite: 13 s; upper /lower jaw: 30 s; 1-8 dies: 30 s; impression: 120 s |
| Scanning Principle | Structured Light 3D Scanning |
| Temperature | 0℃ to 30 ℃（higher temperature will affect the scanning result) |
| Dimension | 260 mm * 270 mm * 420 mm |
| Weight | 5 kg |
| Output Format | STL, OBJ |
| Interface | USB 3.0 |
| Power | DC 24 V |
Business Case
Medical
3D Scanners for Dental Prosthetics, Dental Orthodontics Applications
Use AutoScan 3D scanner to get data of teeth model, and then input data into software Shining3D-DentalCAD to do restorations and orthotics, finally input the processed data input CNC machine or RP machine to make dentures.
